MULTIPLE-USE SCREW-INSERTION UNIT MSE 2

BIHLER MULTIPLE-USE SCREW-INSERTION UNIT MSE 2

Highlights MSE 2

Compact processing unit for quick and reliable joining of bolted connections

  • Up to 180 connection operations/min. (only screw-in process)
  • Modular design: sub-system (for inserting only) or complete system (separating, positioning and inserting)
  • Integrated process monitoring through control system e.g. screw check, revolutions, insertion path
  • Special version can also be used for spring coiling



Technical Data

Complete system incl. positioning
Screw type: Phillips, torx, slotted
Output: max. 140 1/min.
Feed speed: 424 mm/s
Stroke: 50 mm
Screw size: max. M8
  Request form ►

Technology in Motion - MSE 2

Brochure - MSE multiple-use screw insertion unit
