RADIAL GRIPPER FEED UNIT RZV 2.1

BIHLER RADIAL GRIPPER FEED UNIT RZV 2.1

Highlights RZV 2.1

Patented, compact feeding system for highly dynamic and secure positioning of strip or wire material

  • Variable feed lengths from zero to infinite – even various feed lengths (forwards and backwards) in one work cycle
  • Gentle treatment of the material due to multiple clamping via a compensation system, the clamping pressure is allocated to the three grippers
  • Exact transport is ensured also in case of thickness tolerances of strip material
  • Achieves faster feed times than mechanical feeds
  • Conversion from wire to strip without setup


Efficient use: RZV 2.1 in hairpin production



Technical Data

Stroke rate:

max. 1,200 strokes/min.
(20 mm feed length)

Feeding speed:

max. 3.2 m/s

Feeding force:

1,000 N

Feeding accuracy:

+/- 0.02 mm

Hydraulic clamping
pressure
:

3,000 N - 7,000 N

Transport temperature:

max. 60°

Strip thickness:

max. 9.0 mm

Strip width:

max. 300 mm

Wire diameter:

max. 9.0 mm

Technology in Motion - RZV 2.1

Flyer RZV 2.1
Radial gripper feed unit
