SERVO STAMPING AND FORMING MACHINE BNC 4 (MULTI-SLIDE MACHINE)

Highlights BNC 4

Standardized servo manufacturing system for a highly productive manufacture of classical stamped and formed parts

  • Full tool compatibility with MRP machines (UB2, UB2B, UB3, UB3B, UB4, UB4B)
  • Significant increase in output
  • Easier and faster machine set-up
  • Minimum tooling time
  • Rapid response to short-term customer requests
  • Maximum process safety and product quality



Technical Data

Stroke rate: variable drive control up to max. 300 1/min.
Press: nominal stamping capacity 200 kN, stroke 12 mm
Servo units: max. nominal forming capacity 31 kN, max. stroke 100 mm
Feed length: servo feed: any feed length
Material: max. strip thickness: 4 mm, max. strip width 40 mm, max. wire Ø 4 mm (depending on material and process)
Dimensions: width 2,600 mm x depth 1,900 mm x height 2,650 mm
Weight approx. 4,500 kg (without tooling)
